    FTTH 1.5m Pigtail 8 Way 1x8 SC/APC Passive Optical Splitter

    Ask Lasest Price
    Brand Name : UNIFIBER-OEM
    Model Number : 8 Way Passive Optical Splitter
    Certification : ROHS
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 1000pcs/day
    Delivery Time : 5~7 Business days
    • Product Details
    • Company Profile

    FTTH 1.5m Pigtail 8 Way 1x8 SC/APC Passive Optical Splitter

    FTTH 8 Way Passive Optical Splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to realize optical signal power splitting.UNIFIBER provides whole series of 1xN and 2xN splitter products that are tailored for specific applications. All products meet GR-1209-CORE and GR-1221-CORE requirements.


    Features

    Uniform power splitting

    Compact size and various package

    High reliability

    Low insertion loss and low PDL
    Excellent environmental stability


    Application

    FTTX Solutions & CATV systems
    Passive Optical Networks (PON)
    LAN,WAN and Metro Networks


    Specification

    Parameters
    Parameters
    1×2
    1×4
    1×8
    1×16
    1×32
    1×64
    1×128
    Operating Wavelength(nm)
    1260~1650
    Fiber Type
    G657A1 or customer specified
    Insertion Loss (dB)(P/S Grade)
    3.8/4.0
    7.1/7.3
    10.2/10.5
    13.5/13.7
    16.5/16.9
    20.5/21.0
    23.8/24.2
    Loss Uniformit(dB)
    0.4
    0.6
    0.8
    1.2
    1.5
    2
    2.5
    Polarization Dependent Loss(dB)
    0.2
    0.2
    0.2
    0.25
    0.3
    0.35
    0.4
    Return Loss(dB)(P/S Grade)
    55/50
    55/50
    55/50
    55/50
    55/50
    55/50
    55/50
    Directivity(dB)
    55
    55
    55
    55
    55
    55
    55
    Wavelength Dependent Loss(dB)
    0.3
    0.3
    0.3
    0.5
    0.5
    0.5
    0.5
    Temperature Stability (-40~85℃)(dB)
    0.4
    0.4
    0.4
    0.5
    0.5
    0.5
    0.5
    Operating Temperature(℃)
    -40~+85
    Storage Temperature(℃)
    -40~+85
    Device Dimension(mm)
    40×4×4
    40×4×4
    40×4×4
    50×7×4
    50×7×4
    60×12×4
    N/A
    Module Dimension(mm)
    100×80×10
    120×80×18
    141×115×18
    Mini-Module Dimension(mm)
    50×7×4
    60×12×4
    80×20×6
    100×40×6
    N/A
    Storage Temperature(℃)
    -40~+85
    Package dimension(mm)
    Φ5.5x34 (L38 for 900um Loose tube)
