    FC/APC Plug In Fixed M/F 200mW Single Mode Optic Attenuator

    Ask Lasest Price
    Brand Name : UNIFIBER-OEM
    Model Number : UNFAFCA
    Certification : ROHS
    Price : Negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 10000pcs/day
    Delivery Time : 3-5days
    • Product Details
    • Company Profile

    FC/APC Plug In Fixed M/F 200mW Single Mode Optic Attenuator

    Precision FC/APC Plug-in fixed M/F fiber optic attenator single mode 1~25dB attenuation

    FC Build Out Fiber Attenuators include FC/UPC fiber attenuators and FC/APC Female to Male Fiber Attenuators. they are commonly used in fiber optic communications to the the power level of a fiber cable by controlling the amount of signal loss that is passed through the signal. with wide attenuation range from 1dB to 25dB.It has the optical fiber connector at one side and the other side is a female type fiber optic adapter, fiber optic attenuator name is based on the connector type and the attenuation level.


    Features

    High-power light source durability
    Wavelength independence

    Attenuation levels ranging from 1dB to 25dB
    1310nm, 1550nm and 1310/1550nm dual wave lengths


    Application
    CATV Fiber Optic Sensor;
    Local Area Networks(LANs);
    Optic Instrumentation;
    Erbium Doped Fiber Amplifiers (EDFA)
    Dense Wave Division Multiplexers (DWDM)
    Overpowered fiber optic systems
    Testing instrumentation.
    Optical Fiber Communication Network;
    Passive optical networks;

    Specification
    Attenuation Range
    0-25dB
    Attenuation Accuracy
    ±0.5dB(1dB-10dB)
    ±1.0dB(11dB-25dB)
    Available Wavelengths
    1310nm,1550nm,1310&1550nm
    Wavelength Dependence
    <0.3dB Change in insertion loss for 1310-1550nm
    Retuen Loss
    ≥55dB(UPC)
    ≥65dB(APC)
    Polarization Dependent Loss
    ≤0.2dB
    Temperature Range
    -40-80°C(≤0.2dB in insertion loss)
    Humidity Range
    ±0.2dB Change in 10% to 90% relative Humidity Range
    Vibration
    ≤0.1dB Change between 10Hz to 55Hz
    Drop
    ±0.2dB after 8 drops from 1.8meters onto a hard surface
    Maximum Optical Input Power
    200mW

    FC/APC Plug In Fixed M/F 200mW Single Mode Optic AttenuatorFC/APC Plug In Fixed M/F 200mW Single Mode Optic AttenuatorFC/APC Plug In Fixed M/F 200mW Single Mode Optic Attenuator
