    Huawei Mini Sc Ftth Flat Drop Fiber Cable Preconnectorized Grey Lszh G657a2 150m

    Ask Lasest Price
    Brand Name : Unifiber or OEM
    Model Number : Mini SC FTTH Preconnectorized drop cable
    Certification : ROHS
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 500pcs/day
    Delivery Time : 3~5 days
    • Product Details
    • Company Profile

    Huawei Mini Sc Ftth Flat Drop Fiber Cable Preconnectorized Grey Lszh G657a2 150m

    The mini SC connector is factory-terminated, environmentally sealed and hardened connectors to reduce the cost and the time of drop cable deployment in optical access networks.The Mini SC cable assembly is specifically designed to significantly reduce required drop cable installation and compatible to Huawei device.
    Mini SC assemblies provide a robust and sealed connection solution for fiber to the home (FTTH) connectivity.This Mini SC pre-terminated OSP drop cables provide easy FTTx (Fiber-To-The-X) installation and termination using existing hardware and installation methods for drops to homes and businesses. it is compatible with industry standard OSP terminals.


    Features
    1. Cost effective solution for in house termination
    2. IP67 Water immersion and Dust protection for hash environment ·
    3. Chemical Resistance ·
    4. Simple assembly requiring no special tools ·
    5. Push-pull insertion with bayonet-style mechanical latch provides easy installation and removal
    6. Durable mechanical mating, minimum of 500 matings
    7. Wide range of operational temperature for outside plant -40 to+85°C
    8. SC/APC IL<0.3 typically.
    9.100% optically tested to ensure quality performance assemblies.


    Application
    1. Used 1n:
    2. Telecom networks 5G tower;
    3.CATV, LAN&WAN.
    4. Broadband;
    5. Huawei CPRI, FTTP, FTTA


    item
    value
    Model Number
    Mini SC FTTH Preconnectorized drop cable
    Type
    Fiber Optic Pigtail
    Length
    100M /200M /300M/Customized
    Insertion loss
    ≤0.2dB(typical) ≤0.3dB(max)
    Return loss
    ≥60dB
    Strength of Coupling Mechanism
    100N
    Endurance
    Mating and Demating 500 Cycles
    Fiber count
    1core
    Cable Diameter
    2*5mm
    Fiber Type
    G657B3/G657A2
    Strength Member
    2*0.5 FRP/Steel
    Jacket Material
    LSZH Customized
    Working temperature
    -40 to + 85℃
    Warranty Time
    1 year
