    G657A2 E2000 APC Fiber Optic Pigtail LSZH Jacket Spring Loaded Shutter

    Ask Lasest Price
    Brand Name : Unifiber or OEM
    Model Number : E2000/APC fiber optic pigtail
    Certification : ROHS
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 10000pcs/day
    Delivery Time : 3~5 days
    • Product Details
    • Company Profile

    G657A2 E2000 APC Fiber Optic Pigtail LSZH Jacket Spring Loaded Shutter

    G657A2 E2000 APC Fiber Optic Pigtail Spring Loaded Shutter

    e2000 fiber optic pigtail includes e2000 single mode or multimode fiber optic pigtail with 9/125um,50/125um,62.5/125um indoor fiber optic cable. that is OS1,OM1,OM2,OM3 even OM4 fiber optic cable.the usual polishing type is pc,upc and apc for the e2000 fiber optic pigtail.
    E2000 Single mode Multimode Fiber Optic Pigtails are widely used as its good performance.E2000 optic pigtail features a spring-loaded shutter used to protect the ferrule from dust and E2000 ratches. we supplies possibly the highest quality E2000 optic pigtails available.which address the highest of specifications encountered in the telecommunications market.


    Application:

    1. E2000 fiber optic pigtail applications
    2. WANs, LANs, CATV
    3. Metrology, Railway, Industry

    Performance

    ItemSM(Single Mode)MM(Multimode)
    Fiber Cable TypeG652D,G657AOM1OM2/OM3/OM4
    Fiber Diameter (um)9/12562.5/12550/125
    Cable OD (mm)0.9/1.6/1.8/2.0/2.4/3.0
    Endface TypePCUPCAPCUPCUPC
    Typical Insertion Loss (dB)<0.2<0.15<0.2<0.1<0.1
    Return Loss (dB)>45>50>60/
    Insert-pull Test (dB)<0.2<0.3<0.15
    Interchangeability (dB)<0.1<0.15<0.1
    Anti-tensile Force (N)>70
    Temperature Range (℃)-40~+80

    G657A2 E2000 APC Fiber Optic Pigtail LSZH Jacket Spring Loaded ShutterG657A2 E2000 APC Fiber Optic Pigtail LSZH Jacket Spring Loaded ShutterG657A2 E2000 APC Fiber Optic Pigtail LSZH Jacket Spring Loaded Shutter
