OEM 19 Inch Rack Mount Chassis 1U Angled SC LC Fiber Optic Patch Panel

Ask Lasest Price
Brand Name :	Unifiber or OEM
Model Number :	Fiber Patch Panel 12 Ports
Certification :	ROHS
Price :	Negotiable
Payment Terms :	L/C, T/T
Supply Ability :	500pcs/day
Delivery Time :	3~5 days

Add to Cart

Product Details
Company Profile

OEM 19 Inch Rack Mount Chassis 1U Angled SC LC Fiber Optic Patch Panel

19 inch Rackmount Chassis 1U 12/24 Ports Angled SC/LC

Features:
1. 19-inch standard size, fit for 19-inch rack, 23-inch size is
available on request.
2. Standard size is 1U, 2U, or 4U are available on request
3. 12,24,48,96Port optional
4. Suitable for SC, FC, ST,LC adapter, duplex and simplex both
available.
5. Smart Design to supply firm protect for optic cable terminal
connection and optic fiber adapter installation
6. Provide termination, protection, connection, management of fiber
optic cable
7. RoHS compliant
8. Full assembly (loaded) or empty panel optional
9. Black or White color

Applications:
1. Fiber Optic Transmission System
2. CATV Networks
3. Local Area Network
4. Testing/Measurement Instruments

Advantage:
1. UL certificate makes the quality lever be the best.
2. Independent research and development, Can be modified according
to customer requirements
3. OEM package available, we can print your colored logo, print
your OEM box, OEM Carton

We support fiber capacity	12/24/48/72/96/144 cores
Fiber Port	FC, SC, ST and LC
Number of ODF disks	12 for 1, 24 for 2, 48 for 4, 72 for 6, 96 for 8, and 144 for 12
Working temperature	-10 °C ~ +40 °C
Storage temperature	-25 ° C ~ +55 ° C
Relative humidity	≤ 85% (+30 ° C)
Atmospheric pressure	70Kpa~106Kpa
Nominal operating wavelength	850nm, 1310nm, 1550nm
Insertion loss	≤ 0.5dB
Return loss	PC ≥ 40dB, UPC ≥ 50dB, APC ≥ 60dB
Electrical strength	≥3KV(DC)/1min without breakdown
Insulation resistance	≥1000MΩ/500V (DC)
Life	≥1000 times
Application range	Small and medium-sized wiring system for fiber to the cell, fiber to the building, remote module office and wireless base station
