    Simplex LC 10G Bidi SFP Transceiver Module 10km Tx1330nm Rx1270nm

    Ask Lasest Price
    Brand Name : UNIFIBER or OEM
    Model Number : Single Mode 10G Bidi SFP Transceiver Module 10km
    Certification : ROHS
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 1000pcs/day
    Delivery Time : 3-5days
    • Product Details
    • Company Profile

    Simplex LC 10G Bidi SFP Transceiver Module 10km Tx1330nm Rx1270nm

    Features
    1-Fiber Bi-Directional SFP Optical Transceiver
    Up to 10.3 Gbps Bi-directional Data Links
    Compliant with SFP+ MSA
    Compliant to IEEE 802.3ae 10GBASE-BX
    SFF-8472 Digital Diagnostic Function
    Simplex LC Connector
    DFB TX1270nm PIN RX1330nm DFB TX 1330nm PIN RX1270nm
    Distance Up to 10km
    AC/AC Coupling according to MSA
    Single +3.3 V Power Supply
    RoHS Compliant
    Specifications
    Part Number: SFP-10GBiDi-10
    Device Type: SFP+ BiDi
    Package: SFP+
    Data Rate: 10.3Gbps
    Wavelength: 1270nm/1330nm
    Distance/Power Budget: 10km
    Optical ComponentsLD: DFB
    PD: PIN
    Output Power: -5~0dBm
    Receiver Sensitivity: -14dBm
    Power Supply Voltage: 3.3V
    Connector: Single LC
    Fiber Type: SMF
    Operating Temperature: 0~70 °C
    DDMI: With
    Application:
    10G/ 10G FC
    Compatiblity: All Brands
    Applications
    10GBASE-LR/LW at 10.3125Gbps
    Other Optical Links
    155M/622M BiDi SFP LC/SC155M BiDi SFP LC/SC 3km/20km/40km/80km/120km with DDM optional
    4/2/1G BIDI SFP LC/SC4/2/1G BiDi SFP LC/SC 3km/20km/40km/80km/120km with DDM optional
    10G SFP BiDiSFP+ BiDi 1270 20kmSFP+ BiDi 20km Tx1270nm/Rx1330nm LC
    SFP+ BiDi 1330 20kmSFP+ BiDi 20km Tx1330nm/Rx1270nm LC
    SFP+ BiDi 1270 40kmSFP+ BiDi 40km Tx1270nm/Rx1330nm LC
    SFP+ BiDi 1330 40kmSFP+ BiDi 20km Tx1330nm/Rx1270nm LC
    SFP+ BiDi 1270 60kmSFP+ BiDi 60km Tx1270nm/Rx1330nm LC
    SFP+ BiDi 1330 60kmSFP+ BiDi 60km Tx1330/Rx1270nm LC
    SFP+ BiDi 1490 80kmSFP+ BiDi 80km Tx1490/Rx1550nm LC
    SFP+ BiDi 1550 80kmSFP+ BiDi 80km Tx1550/Rx1490nm LC
    10G XFP BiDiXFP BiDi 1270 20kmXFP BiDi 20km Tx1270nm/Rx1330nm LC
    XFP BiDi 1330 20kmXFP BiDi 20km Tx1330nm/Rx1270nm LC
    XFP BiDi 1270 40kmXFP BiDi 40km Tx1270nm/Rx1330nm LC
    XFP BiDi 1330 40kmXFP BiDi 40km Tx1330nm/Rx1270nm LC
    XFP BiDi 1270 60kmXFP BiDi 60km Tx1270nm/Rx1330nm LC
    XFP BiDi 1330 60kmXFP BiDi 60km Tx1330nm/Rx1270nm LC
    XFP BiDi 1490 80kmXFP BiDi 80km Tx1490/Rx1550nm LC
    XFP BiDi 1550 80kmXFP BiDi 80km Tx1550/Rx1490nm LC
